Hyperparameter Optimization

Default hyperparameters are a reasonable starting point, never the finish line. Width, depth, dropout, and the activation function interact in ways that depend on your data, and the only reliable way to find a good combination is to search. DeepTab ships a single method, optimize_hparams(), that runs Gaussian-process Bayesian optimization over a search space derived automatically from each model’s configuration, prunes unpromising trials early, and writes the winning settings straight back into the estimator’s config so the next fit() uses them.

This tutorial explains exactly what happens inside that method, then walks through a complete, runnable example for each of the three task types DeepTab supports: regression, distributional regression (the *LSS family), and classification. The same method drives all three; only the data and one keyword change.

Note

The notebook linked above is generated from this same tutorial content. The markdown page is the readable lesson; the notebook is the executable copy.

What You Will Learn

How optimize_hparams() turns a model config into a search space and what the objective actually measures.
Why the search direction is the same for every task, and how epoch-level pruning saves time.
How to tune a regressor, a distributional regressor, and a classifier with the same API.
How to inspect the search space with get_search_space() before spending compute.
How to fix parameters with fixed_params and override ranges with custom_search_space.

How `optimize_hparams()` Works

The method is intentionally small on the surface and does a lot underneath. Here is the full lifecycle of a single call, in order.

Build the search space. get_search_space(config, fixed_params, custom_search_space) walks the fields of the model’s config dataclass. Every field that has a known range (for example d_model, dropout, activation) becomes a search dimension; every field listed in fixed_params is set on the config and excluded from the search.
Establish a baseline. The model is trained once with the current config to record a baseline validation loss and the validation loss reached at the pruning epoch. These two numbers seed the pruning thresholds.
Run Bayesian optimization. skopt.gp_minimize fits a Gaussian-process surrogate to the trials seen so far and proposes the next configuration where it expects the largest improvement. This is far more sample-efficient than grid or random search because each new trial is informed by all previous ones.
Evaluate each trial. For every proposed configuration the method writes the values onto the config, rebuilds the model with the task-aware builder, trains it (with pruning enabled), and measures the validation loss.
Prune early. If a trial’s loss at prune_epoch is worse than 1.5x the best epoch loss seen so far, training for that trial stops early instead of running all max_epochs. Hopeless configurations are abandoned quickly.
Write back the winner. After all trials, the best configuration is written into model.config. The returned list is the raw best vector in search-space order; the durable result is the mutated config, so the very next fit() trains the tuned model.

The objective: one direction for every task

The quantity being minimized is the Lightning validation loss, which is the training objective itself:

Task	Estimator suffix	Validation loss
Regression	`*Regressor`	Mean squared error
Classification	`*Classifier`	Cross-entropy
Distributional regression	`*LSS`	Negative log-likelihood

Because the objective is always the training loss, it is always defined and always lower-is-better. That keeps the optimizer’s direction identical across tasks and removes any mismatch between what the search optimizes and what the model trains on. You never select the metric direction yourself.

Key parameters

Parameter	Meaning
`X`, `y`	Training features and target. The search trains on these.
`X_val`, `y_val`	Validation split. The objective is measured here. Always provide it.
`time`	Number of optimization trials. Must be at least 10 (the surrogate needs initial points before it can model the space).
`max_epochs`	Maximum epochs per trial. Combined with early stopping and pruning, most trials finish sooner.
`prune_by_epoch`	When `True`, prune by the loss at `prune_epoch`; when `False`, prune by the best validation loss so far.
`prune_epoch`	The epoch at which a trial is judged for pruning.
`fixed_params`	A `{field: value}` dict of config fields to hold constant and exclude from the search.
`custom_search_space`	A `{field: skopt.space.Dimension}` dict that overrides or adds ranges for specific fields.

Important

time is the single biggest cost lever. Each trial trains a full model, so a search with time=20 trains up to twenty models. Keep it small while prototyping, raise it for a final search, and always run the search on the training and validation splits only. The test set must never be visible to it.

Setup

import numpy as np
import pandas as pd
from sklearn.datasets import make_classification, make_regression
from sklearn.metrics import accuracy_score, log_loss, mean_squared_error, r2_score
from sklearn.model_selection import train_test_split
from skopt.space import Categorical, Real

from deeptab.configs import MLPConfig, PreprocessingConfig, TrainerConfig
from deeptab.core.reproducibility import set_seed
from deeptab.hpo import get_search_space
from deeptab.models import MLPClassifier, MLPLSS, MLPRegressor

RANDOM_STATE = 42

Note

For a quick demonstration these tutorials train with very low max_epochs and patience (5 and 2). Treat these as placeholders and choose values that match your own compute budget and problem. As a starting point, at least max_epochs=100 and patience=10 are recommended for meaningful results.

We use the MLP estimators throughout. They train quickly, which keeps the search affordable, and they expose a compact, easy-to-read search space. Everything here works identically for any other DeepTab estimator (FT-Transformer, ResNet, TabM, NODE, and the rest); the only difference is that richer backbones expose more fields to tune, so their searches cost more per trial.

A shared preprocessing and trainer configuration keeps the three examples comparable:

PREPROC = PreprocessingConfig(
    numerical_preprocessing="ple",   # piecewise-linear encoding of numericals
    n_bins=64,
    categorical_preprocessing="int",
)
TRAINER = TrainerConfig(max_epochs=5, batch_size=256, patience=2)

Inspecting the Search Space First

Before spending compute, look at what will actually be searched. get_search_space() returns the parameter names and their skopt ranges for a given config. This is the exact call optimize_hparams() makes internally, so it is a faithful preview.

names, space = get_search_space(MLPConfig())
for name, dim in zip(names, space):
    print(f"{name:22s} {dim}")

embedding_activation   Categorical(categories=('ReLU', 'SELU', 'Identity', 'Tanh', 'LeakyReLU'), ...)
d_model                Categorical(categories=(32, 64, 128, 256, 512, 1024), ...)
layer_norm_eps         Real(low=1e-07, high=0.0001, ...)
activation             Categorical(categories=('ReLU', 'SELU', 'Identity', 'Tanh', 'LeakyReLU', 'SiLU'), ...)
dropout                Real(low=0.0, high=0.5, ...)

The search space is derived from the model config, so only fields that belong to MLPConfig and have a known range appear. The five dimensions above mean each trial chooses an embedding activation, a hidden width (d_model), a layer norm epsilon, a block activation, and a dropout rate. Training settings such as the learning rate live on TrainerConfig, not the model config, so they are not part of this search by default. Reading this list first tells you precisely what the optimizer can and cannot change.

Regression

We start with a straightforward regression problem: twenty numerical features, ten of them informative, with moderate noise.

X_arr, y = make_regression(
    n_samples=4000, n_features=20, n_informative=10, noise=12.0, random_state=RANDOM_STATE
)
X = pd.DataFrame(X_arr, columns=[f"num_{i}" for i in range(X_arr.shape[1])])

X_train, X_tmp, y_train, y_tmp = train_test_split(X, y, test_size=0.3, random_state=RANDOM_STATE)
X_val, X_test, y_val, y_test = train_test_split(X_tmp, y_tmp, test_size=0.5, random_state=RANDOM_STATE)
print(f"Train: {len(y_train)}  |  Val: {len(y_val)}  |  Test: {len(y_test)}")

First, a baseline with default hyperparameters. This is the number to beat.

set_seed(RANDOM_STATE)
baseline = MLPRegressor(
    model_config=MLPConfig(),
    preprocessing_config=PREPROC,
    trainer_config=TRAINER,
    random_state=RANDOM_STATE,
)
baseline.fit(X_train, y_train, X_val=X_val, y_val=y_val, random_state=RANDOM_STATE)
base_r2 = r2_score(y_test, baseline.predict(X_test))
print(f"baseline R2: {base_r2:.4f}")

Now run the search. Note what is not here: there is no regression= argument. The estimator already knows it is a regressor, so the task type is inferred for you. The objective is the validation mean squared error.

set_seed(RANDOM_STATE)
tuned = MLPRegressor(
    model_config=MLPConfig(),
    preprocessing_config=PREPROC,
    trainer_config=TRAINER,
    random_state=RANDOM_STATE,
)

best = tuned.optimize_hparams(
    X_train, y_train,
    X_val=X_val, y_val=y_val,
    time=15,              # 15 trials (must be at least 10)
    max_epochs=5,
    prune_by_epoch=True,  # judge each trial by its loss at prune_epoch
    prune_epoch=2,
)
print("Best vector:", best)
print("Tuned dropout:", tuned.config.dropout, "| d_model:", tuned.config.d_model)

optimize_hparams() has already written the winning values into tuned.config, so a final clean fit trains on the selected configuration. Compare against the baseline on the held-out test set:

set_seed(RANDOM_STATE)
tuned.fit(X_train, y_train, X_val=X_val, y_val=y_val, random_state=RANDOM_STATE)
tuned_r2 = r2_score(y_test, tuned.predict(X_test))
print(f"baseline R2: {base_r2:.4f}   tuned R2: {tuned_r2:.4f}")

The tuned model is selected purely on validation loss, then scored once on the untouched test set: the honest way to report the benefit of a search.

Distributional Regression

Distributional regression (the *LSS family) predicts the parameters of a full conditional distribution rather than a single point. The objective the search minimizes here is the negative log-likelihood, not a point error. The API is the same as regression with one addition: you choose a distribution family, which is forwarded to the underlying fit() so every trial trains and is scored under that family.

We reuse the regression data, which suits a "normal" family (real-valued, roughly symmetric target).

set_seed(RANDOM_STATE)
lss = MLPLSS(
    model_config=MLPConfig(),
    preprocessing_config=PREPROC,
    trainer_config=TRAINER,
    random_state=RANDOM_STATE,
)

best_lss = lss.optimize_hparams(
    X_train, y_train,
    X_val=X_val, y_val=y_val,
    family="normal",      # forwarded to fit(): trials train and score under this family
    time=15,
    max_epochs=5,
    prune_by_epoch=True,
    prune_epoch=2,
)
print("Best vector:", best_lss)
print("Selected family:", lss.family_name)

The search optimizes the validation negative log-likelihood, the same loss the LSS model trains on. After the search, fit once more and evaluate with the family’s proper scoring rules:

set_seed(RANDOM_STATE)
lss.fit(X_train, y_train, family="normal", X_val=X_val, y_val=y_val, random_state=RANDOM_STATE)
scores = lss.evaluate(X_test, y_test)
for name, value in scores.items():
    print(f"{name:20s} {value:.4f}")

evaluate() returns the default metrics for the chosen family (for the normal family these are CRPS, RMSE, and MAE), letting you confirm the tuned distribution is genuinely better calibrated. The search itself optimizes the negative log-likelihood; these metrics are how you report the result afterwards. For a deeper treatment of distributional models, see the Uncertainty Quantification tutorial.

Note

The family you pass to optimize_hparams() must match the one you pass to the final fit(). The search tunes architecture and regularization for that family; switching families afterwards would discard the assumption the search optimized under.

Classification

Classification works exactly like regression. The estimator infers the task, and the objective becomes the validation cross-entropy. We build a binary problem with a few redundant and noise features to give the search something to do.

Xc_arr, yc = make_classification(
    n_samples=4000, n_features=20, n_informative=10, n_redundant=4,
    n_classes=2, class_sep=0.8, random_state=RANDOM_STATE,
)
Xc = pd.DataFrame(Xc_arr, columns=[f"num_{i}" for i in range(Xc_arr.shape[1])])

Xc_train, Xc_tmp, yc_train, yc_tmp = train_test_split(Xc, yc, test_size=0.3, random_state=RANDOM_STATE)
Xc_val, Xc_test, yc_val, yc_test = train_test_split(Xc_tmp, yc_tmp, test_size=0.5, random_state=RANDOM_STATE)

Baseline first:

set_seed(RANDOM_STATE)
clf_base = MLPClassifier(
    model_config=MLPConfig(),
    preprocessing_config=PREPROC,
    trainer_config=TRAINER,
    random_state=RANDOM_STATE,
)
clf_base.fit(Xc_train, yc_train, X_val=Xc_val, y_val=yc_val, random_state=RANDOM_STATE)
base_acc = accuracy_score(yc_test, clf_base.predict(Xc_test))
print(f"baseline accuracy: {base_acc:.4f}")

Then the search:

set_seed(RANDOM_STATE)
clf = MLPClassifier(
    model_config=MLPConfig(),
    preprocessing_config=PREPROC,
    trainer_config=TRAINER,
    random_state=RANDOM_STATE,
)

best_clf = clf.optimize_hparams(
    Xc_train, yc_train,
    X_val=Xc_val, y_val=yc_val,
    time=15,
    max_epochs=5,
    prune_by_epoch=True,
    prune_epoch=2,
)

set_seed(RANDOM_STATE)
clf.fit(Xc_train, yc_train, X_val=Xc_val, y_val=yc_val, random_state=RANDOM_STATE)
tuned_acc = accuracy_score(yc_test, clf.predict(Xc_test))
print(f"baseline accuracy: {base_acc:.4f}   tuned accuracy: {tuned_acc:.4f}")

The search minimizes validation cross-entropy, a smoother and better-behaved target than accuracy, while you report accuracy (or any metric you care about) on the test set afterwards. Optimizing the loss and reporting the metric is the standard, robust separation.

Customizing the Search

The default search space is sensible, but you will often want to narrow it, widen it, or pin certain choices. Two arguments give you full control, and both are passed straight through to get_search_space().

Fixing parameters

fixed_params sets config fields to a constant and removes them from the search. This shrinks the space so the optimizer spends its trial budget on the choices that matter to you. Note that supplying your own fixed_params replaces the default dict, so include any defaults you still want to keep.

set_seed(RANDOM_STATE)
narrow = MLPRegressor(
    model_config=MLPConfig(),
    preprocessing_config=PREPROC,
    trainer_config=TRAINER,
    random_state=RANDOM_STATE,
)

best_narrow = narrow.optimize_hparams(
    X_train, y_train,
    X_val=X_val, y_val=y_val,
    time=12,
    max_epochs=5,
    fixed_params={
        "pooling_method": "avg",
        "head_skip_layers": False,
        "head_layer_size_length": 0,
        "cat_encoding": "int",
        "head_skip_layer": False,
        "use_cls": False,
        "activation": "ReLU",   # pin the activation; do not search it
    },
)
print("Tuned activation stays ReLU:", type(narrow.config.activation).__name__)

Note

You can pin any searchable field this way, including categorical choices and activations. Activation names (such as "ReLU" or "SELU") are mapped to their nn.Module instances automatically, exactly as they are during the search.

Overriding ranges

custom_search_space is a dict mapping a field name to a skopt dimension (Real, Integer, or Categorical). It overrides the default range for that field. Use it to restrict d_model to the sizes you can afford, or to widen a dropout range:

set_seed(RANDOM_STATE)
custom = MLPRegressor(
    model_config=MLPConfig(),
    preprocessing_config=PREPROC,
    trainer_config=TRAINER,
    random_state=RANDOM_STATE,
)

best_custom = custom.optimize_hparams(
    X_train, y_train,
    X_val=X_val, y_val=y_val,
    time=12,
    max_epochs=5,
    custom_search_space={
        "d_model": Categorical([64, 128, 256]),  # smaller, cheaper widths only
        "dropout": Real(0.1, 0.4),               # narrower dropout band
    },
)
print("Tuned d_model in {64,128,256}:", custom.config.d_model)

You can preview the effect of either argument before searching by passing the same values to get_search_space() and printing the result, exactly as in the inspection step above.

Practical Guidance

Always pass a validation split. The objective is measured on X_val/y_val. Without it the search cannot judge generalization.
Start small, then scale. Use time=10 to time=15 while iterating on the space, then raise time for the final run.
Tune pruning to your patience. Lowering prune_epoch prunes sooner and cheaper but risks discarding slow starters; raising it is safer but costs more.
Reproducibility. The optimizer uses a fixed seed internally, so repeated searches on the same data and space explore the same sequence of trials. Call set_seed() before each fit() for fully deterministic training.
Keep the test set sacred. Select on validation, report on test, once.

Next Steps

Skewed-Target Regression: a full regression pipeline that includes an HPO step in context.
Uncertainty Quantification: distributional models, families, and calibration in depth.
Imbalanced Classification: class weights, thresholds, and metrics for skewed labels.
